7700 Series Heavy-Duty Seismic Cabinet

Your request has been sent! A representative will contact you as soon as possible.

Product Information

Product Image

Example of 7700 Series Heavy-Duty Seismic Cabinet

Series

VR7700

Options

  • Busbar assembly
  • Face mounted front door
  • Heavy-duty lifting eyes
  • Key lock
  • Louvered rear door bottom
  • Louvered rear door top
  • Louvered rear door top and bottom
  • Louvered side panel bottom
  • Louvered side panel top
  • Louvered side panel top and bottom
  • Louvered top pan
  • Louvers
  • Mounting "Z" rail
  • Mounting channel
  • Offset mounting channel
  • Power strip assembly
  • Rear horizontal space divider
  • Standard duty lifting eyes
  • Standard mounting angle

Applications

  • Commercially on off-shore oil rigs
  • Communications vehicles
  • Nuclear power plants
  • On board ships
  • Transportable military instrument shelters

Fed Standard 595 Color Chart

Click to View

RAL Color Chart

Click to View

Spec Sheets

Click to View

Brochure

Click to View

Product Notes

  • Cabinet Frame (10 gauge C.R.S.)
  • Removable Side Panels (inside Secured, 16 gauge C.R.S.)
  • Removable Rear Door (16 gauge C.R.S.)
  • Removable Top Cover (16 gauge C.R.S.)
  • Mounting Angles (1 Pair Rear) made from 10 gauge C.R.S. with #10-32 tapped holes per EIA RS-310 specification Finish: Zinc and Bright.
  • Removable Bottom Cover (12 gauge C.R.S.)

Product Variants

Results Per Page:
Item # ▲ Rack Units (U) ▲ Overall Width w/ Panels (in) ▲ Overall Depth w/ Panels (in) ▲ Overall Height (in) ▲ Clear Opening (in) ▲ Hole C-C (in) ▲
VR7700-19-01-24-26 15 24 24 31.25 17.94 18.31
VR7700-19-01-24-31 18 24 24 36.5 17.94 18.31
VR7700-19-01-24-35 20 24 24 40 17.94 18.31
VR7700-19-01-24-42 24 24 24 47 17.94 18.31
VR7700-19-01-24-52 30 24 24 57.5 17.94 18.31
VR7700-19-01-24-61 35 24 24 66.25 17.94 18.31
VR7700-19-01-24-70 40 24 24 75 17.94 18.31
VR7700-19-01-24-78 45 24 24 83.75 17.94 18.31
VR7700-19-01-30-26 15 24 30 31.25 17.94 18.31
VR7700-19-01-30-31 18 24 30 36.5 17.94 18.31
VR7700-19-01-30-35 20 24 30 40 17.94 18.31
VR7700-19-01-30-42 24 24 30 47 17.94 18.31
VR7700-19-01-30-52 30 24 30 57.5 17.94 18.31
VR7700-19-01-30-61 35 24 30 66.25 17.94 18.31
VR7700-19-01-30-70 40 24 30 75 17.94 18.31
VR7700-19-01-30-78 45 24 30 83.75 17.94 18.31
VR7700-19-01-36-26 15 24 36 31.25 17.94 18.31
VR7700-19-01-36-31 18 24 36 36.5 17.94 18.31
VR7700-19-01-36-35 20 24 36 40 17.94 18.31
VR7700-19-01-36-42 24 24 36 47 17.94 18.31
VR7700-19-01-36-52 30 24 36 57.5 17.94 18.31
VR7700-19-01-36-61 35 24 36 66.25 17.94 18.31
VR7700-19-01-36-70 40 24 36 75 17.94 18.31
VR7700-19-01-36-78 45 24 36 83.75 17.94 18.31
VR7700-19-02-24-26 15 24 24 31.25 17.94 18.31
VR7700-19-02-24-31 18 24 24 36.5 17.94 18.31
VR7700-19-02-24-35 20 24 24 40 17.94 18.31
VR7700-19-02-24-42 24 24 24 47 17.94 18.31
VR7700-19-02-24-52 30 24 24 57.5 17.94 18.31
VR7700-19-02-24-61 35 24 24 66.25 17.94 18.31
VR7700-19-02-24-70 40 24 24 75 17.94 18.31
VR7700-19-02-24-78 45 24 24 83.75 17.94 18.31
VR7700-19-02-30-26 15 24 30 31.25 17.94 18.31
VR7700-19-02-30-31 18 24 30 36.5 17.94 18.31
VR7700-19-02-30-35 20 24 30 40 17.94 18.31
VR7700-19-02-30-42 24 24 30 47 17.94 18.31
VR7700-19-02-30-52 30 24 30 57.5 17.94 18.31
VR7700-19-02-30-61 35 24 30 66.25 17.94 18.31
VR7700-19-02-30-70 40 24 30 75 17.94 18.31
VR7700-19-02-30-78 45 24 30 83.75 17.94 18.31
VR7700-19-02-36-26 15 24 36 31.25 17.94 18.31
VR7700-19-02-36-31 18 24 36 36.5 17.94 18.31
VR7700-19-02-36-35 20 24 36 40 17.94 18.31
VR7700-19-02-36-42 24 24 36 47 17.94 18.31
VR7700-19-02-36-52 30 24 36 57.5 17.94 18.31
VR7700-19-02-36-61 35 24 36 66.25 17.94 18.31
VR7700-19-02-36-70 40 24 36 75 17.94 18.31
VR7700-19-02-36-78 45 24 36 83.75 17.94 18.31
VR7700-19-03-24-26 15 24 24 31.25 17.94 18.31
VR7700-19-03-24-31 18 24 24 36.5 17.94 18.31
VR7700-19-03-24-35 20 24 24 40 17.94 18.31
VR7700-19-03-24-42 24 24 24 47 17.94 18.31
VR7700-19-03-24-52 30 24 24 57.5 17.94 18.31
VR7700-19-03-24-61 35 24 24 66.25 17.94 18.31
VR7700-19-03-24-70 40 24 24 75 17.94 18.31
VR7700-19-03-24-78 45 24 24 83.75 17.94 18.31
VR7700-19-03-30-26 15 24 30 31.25 17.94 18.31
VR7700-19-03-30-31 18 24 30 36.5 17.94 18.31
VR7700-19-03-30-35 20 24 30 40 17.94 18.31
VR7700-19-03-30-42 24 24 30 47 17.94 18.31
VR7700-19-03-30-52 30 24 30 57.5 17.94 18.31
VR7700-19-03-30-61 35 24 30 66.25 17.94 18.31
VR7700-19-03-30-70 40 24 30 75 17.94 18.31
VR7700-19-03-30-78 45 24 30 83.75 17.94 18.31
VR7700-19-03-36-26 15 24 36 31.25 17.94 18.31
VR7700-19-03-36-31 18 24 36 36.5 17.94 18.31
VR7700-19-03-36-35 20 24 36 40 17.94 18.31
VR7700-19-03-36-42 24 24 36 47 17.94 18.31
VR7700-19-03-36-52 30 24 36 57.5 17.94 18.31
VR7700-19-03-36-61 35 24 36 66.25 17.94 18.31
VR7700-19-03-36-70 40 24 36 75 17.94 18.31
VR7700-19-03-36-78 45 24 36 83.75 17.94 18.31
VR7700-24-01-24-26 15 29 24 31.25 22.94 23.31
VR7700-24-01-24-31 18 29 24 36.5 22.94 23.31
VR7700-24-01-24-35 20 29 24 40 22.94 23.31
VR7700-24-01-24-42 24 29 24 47 22.94 23.31
VR7700-24-01-24-52 30 29 24 57.5 22.94 23.31
VR7700-24-01-24-61 35 29 24 66.25 22.94 23.31
VR7700-24-01-24-70 40 29 24 75 22.94 23.31
VR7700-24-01-24-78 45 29 24 83.75 22.94 23.31
VR7700-24-01-30-26 15 29 30 31.25 22.94 23.31
VR7700-24-01-30-31 18 29 30 36.5 22.94 23.31
VR7700-24-01-30-35 20 29 30 40 22.94 23.31
VR7700-24-01-30-42 24 29 30 47 22.94 23.31
VR7700-24-01-30-52 30 29 30 57.5 22.94 23.31
VR7700-24-01-30-61 35 29 30 66.25 22.94 23.31
VR7700-24-01-30-70 40 29 30 75 22.94 23.31
VR7700-24-01-30-78 45 29 30 83.75 22.94 23.31
VR7700-24-01-36-26 15 29 36 31.25 22.94 23.31
VR7700-24-01-36-31 18 29 36 36.5 22.94 23.31
VR7700-24-01-36-35 20 29 36 40 22.94 23.31
VR7700-24-01-36-42 24 29 36 47 22.94 23.31
VR7700-24-01-36-52 30 29 36 57.5 22.94 23.31
VR7700-24-01-36-61 35 29 36 66.25 22.94 23.31
VR7700-24-01-36-70 40 29 36 75 22.94 23.31
VR7700-24-01-36-78 45 29 36 83.75 22.94 23.31
VR7700-24-02-24-26 15 29 24 31.25 22.94 23.31
VR7700-24-02-24-31 18 29 24 36.5 22.94 23.31
VR7700-24-02-24-35 20 29 24 40 22.94 23.31
VR7700-24-02-24-42 24 29 24 47 22.94 23.31
VR7700-24-02-24-52 30 29 24 57.5 22.94 23.31
VR7700-24-02-24-61 35 29 24 66.25 22.94 23.31
VR7700-24-02-24-70 40 29 24 75 22.94 23.31
VR7700-24-02-24-78 45 29 24 83.75 22.94 23.31
VR7700-24-02-30-26 15 29 30 31.25 22.94 23.31
VR7700-24-02-30-31 18 29 30 36.5 22.94 23.31
VR7700-24-02-30-35 20 29 30 40 22.94 23.31
VR7700-24-02-30-42 24 29 30 47 22.94 23.31
VR7700-24-02-30-52 30 29 30 57.5 22.94 23.31
VR7700-24-02-30-61 35 29 30 66.25 22.94 23.31
VR7700-24-02-30-70 40 29 30 75 22.94 23.31
VR7700-24-02-30-78 45 29 30 83.75 22.94 23.31
VR7700-24-02-36-26 30 29 36 31.25 22.94 23.31
VR7700-24-02-36-31 35 29 36 36.5 22.94 23.31
VR7700-24-02-36-35 40 29 36 40 22.94 23.31
VR7700-24-02-36-42 45 29 36 47 22.94 23.31
VR7700-24-02-36-52 15 29 36 57.5 22.94 23.31
VR7700-24-02-36-61 18 29 36 66.25 22.94 23.31
VR7700-24-02-36-70 20 29 36 75 22.94 23.31
VR7700-24-02-36-78 24 29 36 83.75 22.94 23.31
VR7700-24-03-24-26 30 29 24 31.25 22.94 23.31
VR7700-24-03-24-31 35 29 24 36.5 22.94 23.31
VR7700-24-03-24-35 40 29 24 40 22.94 23.31
VR7700-24-03-24-42 45 29 24 47 22.94 23.31
VR7700-24-03-24-52 30 29 24 57.5 22.94 23.31
VR7700-24-03-24-61 35 29 24 66.25 22.94 23.31
VR7700-24-03-24-70 40 29 24 75 22.94 23.31
VR7700-24-03-24-78 45 29 24 83.75 22.94 23.31
VR7700-24-03-30-26 15 29 30 31.25 22.94 23.31
VR7700-24-03-30-31 18 29 30 36.5 22.94 23.31
VR7700-24-03-30-35 20 29 30 40 22.94 23.31
VR7700-24-03-30-42 24 29 30 47 22.94 23.31
VR7700-24-03-30-52 30 29 30 57.5 22.94 23.31
VR7700-24-03-30-61 35 29 30 66.25 22.94 23.31
VR7700-24-03-30-70 40 29 30 75 22.94 23.31
VR7700-24-03-30-78 45 29 30 83.75 22.94 23.31
VR7700-24-03-36-26 30 29 36 31.25 22.94 23.31
VR7700-24-03-36-31 35 29 36 36.5 22.94 23.31
VR7700-24-03-36-35 40 29 36 40 22.94 23.31
VR7700-24-03-36-42 45 29 36 47 22.94 23.31
VR7700-24-03-36-52 15 29 36 57.5 22.94 23.31
VR7700-24-03-36-61 18 29 36 66.25 22.94 23.31
VR7700-24-03-36-70 20 29 36 75 22.94 23.31
VR7700-24-03-36-78 24 29 36 83.75 22.94 23.31
VR7700-30-01-24-26 30 35 24 31.25 28.94 29.31
VR7700-30-01-24-31 35 35 24 36.5 28.94 29.31
VR7700-30-01-24-35 40 35 24 40 28.94 29.31
VR7700-30-01-24-42 45 35 24 47 28.94 29.31
VR7700-30-01-24-52 30 35 24 57.5 28.94 29.31
VR7700-30-01-24-61 35 35 24 66.25 28.94 29.31
VR7700-30-01-24-70 40 35 24 75 28.94 29.31
VR7700-30-01-24-78 45 35 24 83.75 28.94 29.31
VR7700-30-01-30-26 15 35 30 31.25 28.94 29.31
VR7700-30-01-30-31 18 35 30 36.5 28.94 29.31
VR7700-30-01-30-35 20 35 30 40 28.94 29.31
VR7700-30-01-30-42 24 35 30 47 28.94 29.31
VR7700-30-01-30-52 30 35 30 57.5 28.94 29.31
VR7700-30-01-30-61 35 35 30 66.25 28.94 29.31
VR7700-30-01-30-70 40 35 30 75 28.94 29.31
VR7700-30-01-30-78 45 35 30 83.75 28.94 29.31
VR7700-30-01-36-26 30 35 36 31.25 28.94 29.31
VR7700-30-01-36-31 35 35 36 36.5 28.94 29.31
VR7700-30-01-36-35 40 35 36 40 28.94 29.31
VR7700-30-01-36-42 45 35 36 47 28.94 29.31
VR7700-30-01-36-52 15 35 36 57.5 28.94 29.31
VR7700-30-01-36-61 18 35 36 66.25 28.94 29.31
VR7700-30-01-36-70 20 35 36 75 28.94 29.31
VR7700-30-01-36-78 24 35 36 83.75 28.94 29.31
VR7700-30-02-24-26 30 35 24 31.25 28.94 29.31
VR7700-30-02-24-31 35 35 24 36.5 28.94 29.31
VR7700-30-02-24-35 40 35 24 40 28.94 29.31
VR7700-30-02-24-42 45 35 24 47 28.94 29.31
VR7700-30-02-24-52 30 35 24 57.5 28.94 29.31
VR7700-30-02-24-61 35 35 24 66.25 28.94 29.31
VR7700-30-02-24-70 40 35 24 75 28.94 29.31
VR7700-30-02-24-78 45 35 24 83.75 28.94 29.31
VR7700-30-02-30-26 15 35 30 31.25 28.94 29.31
VR7700-30-02-30-31 18 35 30 36.5 28.94 29.31
VR7700-30-02-30-35 20 35 30 40 28.94 29.31
VR7700-30-02-30-42 24 35 30 47 28.94 29.31
VR7700-30-02-30-52 30 35 30 57.5 28.94 29.31
VR7700-30-02-30-61 35 35 30 66.25 28.94 29.31
VR7700-30-02-30-70 40 35 30 75 28.94 29.31
VR7700-30-02-30-78 45 35 30 83.75 28.94 29.31
VR7700-30-02-36-26 30 35 36 31.25 28.94 29.31
VR7700-30-02-36-31 35 35 36 36.5 28.94 29.31
VR7700-30-02-36-35 40 35 36 40 28.94 29.31
VR7700-30-02-36-42 45 35 36 47 28.94 29.31
VR7700-30-02-36-52 15 35 36 57.5 28.94 29.31
VR7700-30-02-36-61 18 35 36 66.25 28.94 29.31
VR7700-30-02-36-70 20 35 36 75 28.94 29.31
VR7700-30-02-36-78 24 35 36 83.75 28.94 29.31
VR7700-30-03-24-26 30 35 24 31.25 28.94 29.31
VR7700-30-03-24-31 35 35 24 36.5 28.94 29.31
VR7700-30-03-24-35 40 35 24 40 28.94 29.31
VR7700-30-03-24-42 45 35 24 47 28.94 29.31
VR7700-30-03-24-52 30 35 24 57.5 28.94 29.31
VR7700-30-03-24-61 35 35 24 66.25 28.94 29.31
VR7700-30-03-24-70 40 35 24 75 28.94 29.31
VR7700-30-03-24-78 45 35 24 83.75 28.94 29.31
VR7700-30-03-30-26 15 35 30 31.25 28.94 29.31
VR7700-30-03-30-31 18 35 30 36.5 28.94 29.31
VR7700-30-03-30-35 20 35 30 40 28.94 29.31
VR7700-30-03-30-42 24 35 30 47 28.94 29.31
VR7700-30-03-30-52 30 35 30 57.5 28.94 29.31
VR7700-30-03-30-61 35 35 30 66.25 28.94 29.31
VR7700-30-03-30-70 40 35 30 75 28.94 29.31
VR7700-30-03-30-78 45 35 30 83.75 28.94 29.31
VR7700-30-03-36-26 15 35 36 31.25 28.94 29.31
VR7700-30-03-36-31 18 35 36 36.5 28.94 29.31
VR7700-30-03-36-35 20 35 36 40 28.94 29.31
VR7700-30-03-36-42 24 35 36 47 28.94 29.31
VR7700-30-03-36-52 30 35 36 57.5 28.94 29.31
VR7700-30-03-36-61 35 35 36 66.25 28.94 29.31
VR7700-30-03-36-70 40 35 36 75 28.94 29.31
VR7700-30-03-36-78 45 35 36 83.75 28.94 29.31
